Description
Features
Hydraulic disc brakes- Delivers better power, stability, adjustability, and performance than traditional mechanical brakes.
Long Range- Up to 90 km of range for worry-free exploration. Range extendable with extra batteries.
Removable Battery- The 500Wh removable battery enables easy charging anywhere.
Multi Accessories- Rear rack and optional front basket greatly enhance the e-bike’s versatility and practicality.
Specifications
|
Model Name
|
C11 |
|
Net Weight
|
24.5 kg
|
| Payload | 120 kg |
| Frame |
700C aluminum alloy step-through city frame
|
| Fork |
Suspension fork (40mm travel) with 100mm opening width
|
| Headset | Aluminum alloy bearing headset |
|
Drive Unit
|
500W
|
| Battery | DMEGC/EVE 499.2Wh |
| Display | LCD 1.47 inch |
| Rear Derailleur | SHIMANO TY300D |
| Shifters | 7-speed |
| Chain | KMC Z7 |
| Crank |
Aluminum alloy 52T
|
|
Rear Cogs
|
7-speed (14-28T)
|
| Sensor | 12-magnet speed sensor |
| Brakes | Dual-piston hydraulic disc brake with power cut-off |
| Brake Levers | Hydraulic disc brake |
|
Front Hub
|
Aluminum alloy double-bearing barrel axle hub (quick release front axle)
|
| Rims |
Aluminum alloy double-layer rim
|
| Spokes |
Stainless steel spokes with brass nipples
|
| Tires | CST 27.6*1.57 |
| Seatpost | Aluminum alloy clamp head seatpost (Length: 400mm, Diameter: 33.9mm) |
Geometry
| Rider heights | 5’1″ (155cm) – 6’5″ (195cm) |
| Wheel size | CST 700*40C |
| A-Seat tube | 450 |
| B-Seat tube angle | 73° |
| C-Head tube | 190 |
| D-Head angle | 70.5° |
| E-Top tube length | 605 |
| F-Standover height | 572 |
| G-BB drop | 68 |
| H-Rear Center | 468 |
| I-Wheelbase | 1115 |
| J-Reach | 398 |
| K-Stack | 676 |
| L-Maximum seat height | 1050 |
| M-Minimum seat height | 790 |
| N-Rear rack height | 755 |
| O-Total length | 1820 |
| P-Handlebar height | 1150 |
| Q-Handlebar length | 670 |
| R-Rear Rack Load | 25kg |
| S-Sear rack outer diameter length | 300 |
| T-Rear rack width | 128 |
